The Peak T5 begins where the road ends! It has a torque pedal assist sensor that combines power from the rider and the motor for the ultimate in smoothness and control.
$2,699.00
A wide range drive train and a robust power system make the Magnum Peak T5 an ideal choice for trail riding.
Brand – Bafang
Type – Rear Hub-Drive
Nominal Output – 500 Watts
Peak Output – 750 Watts
Brand – Samsung Cells
Voltage – 48 Volts
Ah – 15Ah
Wh – 720Wh
Chemistry – Li-NMC
Charge Time (from empty) – 7.5 Hours
Minimum Range – 30 Miles (48 Kilometers)
Maximum Range- 50 miles (80 Kilometers)
Display Type- Magnum Branded VeloFox, 8 x 7 cm, Display Screen, Backlit Monochrome LCD, Display Readouts – Battery Level, Assist Level, Current Speed, Power Output, Trip Distance, Odometer, Range, Trip Time.
Drive Mode – Torque Sensor Pedal Assist, Trigger Throttle, Walk Mode
Top Speed – 25 mph with Pedal Assist, 20 mph with Throttle
Lights – Front light controlled from the display. Rear light brake activated. Front Light: 40 lux, Rear Light: 20 lux (Rear light not included)
Frame material – Aluminum Alloy
Frame size – 19” (48 cm)
Fork Details – XCM34-Boost
Gearing details – A11-X 11-Speed
Shifter Details – A11-X 11-Speed
Crank – Aluminum Alloy, 42T, 170mm
Pedals – Wellgo
Stem – Magnum 60mm
Brakes – Logan Hydraulic Disc Brakes
Grips – Black
Saddle – Selle Royal Essenza+
Tire Brand – CST Patrol 27.5 x 2.8
Wheel size – 27.5”
Fenders – Front and Rear Included
Chain – KMC 11-Speed
Seat Tube – 19” (48 cm)
Reach – 14.5” (37 cm)
Stand Over Height – 31” (78.5 cm)
Virtual Top Tube Length – 23.25” (59 cm)
Min Saddle Height – 22” (56 cm)
Max Saddle Height – 31” (78.5 cm)
Width – 28.75” (73 cm)
Wheelbase – 45.75” (116 cm)
Length – 74” (188 cm)
Total Weight – 60 lbs (27.25 kg)
Battery Weight – 9 lbs (4.1 kg)
Rider minimum height – 5’4”
Class – Can be configured to a Class 1, 2, or 3 E-Bike.
Long-range (up to 50 miles) battery for the freedom and power to tackle longer rides
15Ah
50 miles (80 Kilometers) Max Range
7.5 Hours Charge Time
Amplify your effort.
The torque-sensing pedal assist feature adds just the right amount of power from the motor to amplify your effort. It feels just like riding a regular bicycle, but with greater ease and comfort.
The versatile CST Patrol tires offer the perfect balance of low rolling resistance and great traction to handle a variety of trail conditions.
Powerful front and rear Logan 4-Pistion hydraulic disc brakes provide consistent, controlled stops in all conditions, and prolong rim life.
The SR Suntour SCM34-Boost suspension fork offers 120mm of travel, to smooth out rough terrain.
The Microshift 11-speed gear cassette offers a wide variety of gear ratios to even out your effort and speed over changing terrain and trail conditions.
The Bafang gear hub motor provides all the power you need to tackle the toughest trails.
