There’s no other e-bike out there with ride quality, range, and power like this, at a weight that’s light enough to carry. The Turbo Vado SL 4.0 EQ is best for your daily commute, quick errands and getting around town. Extra-bright, built-in lights in front and back mean you’ll see and be seen. DRYTECH fenders keep water and road spray away, and a standard rear rack is always ready for your bags and panniers. This is your go-to for local transportation.
Fully integrated and secure Specialized 320Wh downtube battery w/optional Range Extender compatibility for up to 120 miles of range.
Specialized SL 1.1 custom lightweight motor, peak 240W / 35Nm, 2x you rider amplification (180% assistance), assist up to 28mph.
Turbo SL mounted rear rack, Racktime-compatible for your favorite bags and panniers, and DRYTECH fenders to keep the spray away.
Premium lightweight E5 Aluminum frame.
Clean internal cable routing, fender/rack mounts, and reflective graphics.
Premium hydraulic disc brakes for maximum stopping power.
Bright, integrated front and rear lighting to see and be seen.
Original price was: $3,999.99.$2,900.00Current price is: $2,900.00.
There’s no other e-bike out there with ride quality, range, and power like this, at a weight that’s light enough to carry. The Turbo Vado SL 4.0 EQ is best for your daily commute, quick errands and getting around town. Extra-bright, built-in lights in front and back mean you’ll see and be seen. DRYTECH fenders keep water and road spray away, and a standard rear rack is always ready for your bags and panniers. This is your go-to for local transportation.
Vado 4.0 SL Technical Specifications
FRAMESET
Fork – Rigid full aluminum disc, Boost™ 12x110mm, front- rack-compatible
Seat Binder – Integrated w/ frame
Frame – E5 Aluminum, bottom bracket motor mount, fully integrated downtube battery, internal cable routing, fender and front rack mounts, Smooth Welds
COCKPIT
Stem – Specialized Stealth Stem, alloy, 14 deg, 31.8mm, integrated TCD mount
Handlebars – Specialized, alloy, 9-degree backsweep, 15mm rise, 31.8mm
Saddle – Bridge Sport, hollow cr-mo rails, 155mm
Seat Post – Specialized, alloy, dual-bolt, 25mm offset, 27.2mm
Grips – Specialized Body Geometry Contour, lock-on
BRAKES – Tektro HD-R290, hydraulic disc, 160mm
DRIVETRAIN
Rear Derailleur – SRAM NX, 11-speed
Shift Levers – SRAM NX, 11-speed
Chain – KMC e11S, 11-speed w/ Missing Link™
Crankset – Praxis, Forged alloy M30, custom offset
Chainrings – Praxis, 44T, 104BCD
Cassette – Sunrace, 11spd, 11-42t
Pedals – Specialized Commuter w/ grip tape & reflectors
Headlight – Lezyne Ebike Hecto STVZO E65, 210Lumens, 12V
Taillight – Lezyne Ebike Rear Fender STVZO, 11Lumens, 12V
Kickstand – Specialized kickstand, 40mm mount
Rack – Turbo SL Rack, Closed Platform, direct fender mount, Racktime-compatible, 15kg
Fenders – Specialized DryTech, Aluminum
WHEELS
Rims- 700C disc, 22mm rim depth, 21mm internal width
Front Hub – Specialized alloy front hub disc, sealed cartridge bearings, 12x110mm, Center Lock™, 24h
Rear Hub – Specialized alloy rear hub disc, Center Lock™, sealed cartridge bearings, 12x148mm, 28h
Spokes – DT Swiss Industry
Front Tire – Nimbus II Sport Reflect, 700x38mm
Rear Tire – Nimbus II Sport Reflect, 700x38mm
Inner Tubes – Standard 40mm PV 700×32-50
E-BIKE
Motor – Specialized SL 1.1, custom lightweight motor
UI/Remote – Specialized TCU, 10-LED State of charge, 3-LED Ride Mode display, ANT+/Bluetooth®, w/Handlebar remote
Battery – Specialized SL1-320, fully integrated, 320Wh
Charger – Custom charger, 48V System w/ SL system charger plug
Wiring Harness – Custom Specialized wiring harness w/ chargeport
| S | M | L | XL | |
|---|---|---|---|---|
| Crank Length | 170mm | 172.5mm | 172.5mm | 175mm |
| Handlebar Width | 680mm | 680mm | 680mm | 680mm |
| Stem Length | 60mm | 75mm | 75mm | 90mm |
| Saddle Width | 155mm | 155mm | 155mm | 155mm |
| Seatpost Length | 350mm | 350mm | 350mm | 350mm |
| Stack | 542mm | 574mm | 607mm | 643mm |
| Reach | 397mm | 419mm | 433mm | 442mm |
| Head-Tube Length | 130mm | 161.5mm | 194.5mm | 230mm |
| Head-Tube Angle | 70° | 70.5° | 71° | 71.5° |
| B-B Height | 291mm | 291mm | 291mm | 291mm |
| B-B Drop | 70mm | 70mm | 70mm | 70mm |
| Trail | 78mm | 75mm | 71mm | 68mm |
| Fork Length (full) | 390mm | 390mm | 390mm | 390mm |
| Fork Rake/Offset | 50mm | 50mm | 50mm | 50mm |
| Front-Center | 626mm | 655mm | 675mm | 690mm |
| Chain-Stay Length | 445mm | 445mm | 445mm | 445mm |
| Wheelbase | 1062mm | 1091mm | 1110mm | 1126mm |
| Top-Tube Length (horizontal) | 558mm | 589mm | 613mm | 632mm |
| Bike Stand-Over Height | 791mm | 811mm | 836mm | 861mm |
| Seat-Tube Length | 415mm | 446.5mm | 494.5mm | 535mm |
| Seat-Tube Angle | 73.5° | 73.5° | 73.5° | 73.5° |
